Instructions

STEP 1 : Make the connections as per the instructions given below :
V1 --> SA, V2 --> SB, SA --> D1, SB --> D2,
ⵊ1 --> C1, ⵊ2 --> C2, ⵊ3 --> C3,
C4 --> M1, C5 --> M2, C6 --> M3, M --> R,
T1 --> T4, T2 --> T5, T3 --> T6,
P1 --> P4, P2 --> P5, P3 --> P6

STEP 2 : Click on "CHECK" button for checking the connections.

Note: Click on a label to remove the connection.

STEP 3 : Click on "START" button to perform the experiment.

STEP 4 : Click on "GRAPH" button to open the graph.

STEP 5 : Click on "PRINT" button to print the simulation.

STEP 6 : Click on "RESET" button to reset the simulation.
