Instructions

STEP 1 : Make the connections as per the instructions given below:
Boost Converter
B1 --> V1, B2 --> V2, B1 --> Vin-, B2 --> ⵊ1, ⵊ2 --> Vin+, Vout+ --> B3, Vout- --> B4
Buck-Boost Converter
S1 --> V3, S2 --> V4, S1 --> ⵊ3, ⵊ4 --> Vin+, S2 --> Vin-, Vout+ --> B3, Vout- --> B4

STEP 2 : Click on "CHECK" button for checking the connections.

Note: Click on a label to remove the connection.

STEP 3 : Click on "START" button to perform the experiment.

STEP 4 : Click on "PRINT" button to print the simulation.

STEP 5 : Click on "RESET" button to reset the experiment.
