Instructions

Step 1: Make the connections as per the instructions given below.

• A1 ↔ B1, A2 ↔ B2, A3 → B3, A4 → B4
• B1 ↔ Relay1 COM, B1 ↔ S1
• Relay1 NO ↔ M1, B2 → Relay1 Coil (-)
• Relay1 Coil (+) ↔ S2, B2 ↔ M2
• B3 ↔ Relay2 COM, B3 ↔ S1
• Relay2 NO ↔ M3, B4 ↔ Relay2 Coil (-)
• Relay2 Coil (+) ↔ S2, B4 ↔ M4

Step 2: Verify Connections

Click the "CHECK" button to ensure all connections are properly made.

Note: Click on the label to remove a connection if needed.

Step 3: Activate the Circuit

Click on the switch to start the simulation.

Step 4: Generate the Graph

Click on the "GRAPH" button to visualize the battery performance.

Step 5: Click on "RESET" button to reset the simulation.
